New DC3V/5V/12V 1/2'' Brass Electric Motorized Valve (T15-B2-A)

FOB Reference Price:Get Latest Price
US $24-26 / Sets | 1 Set/Sets 30pcs/carton (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Standard or Nonstandard:
Standard
Structure:
Straight Through Type
Pressure:
Medium Pressure
Power:
Electric, Electric,Motor
Material:
Brass
Temperature of Media:
Normal Temperature
Media:
Water
Port Size:
1/2"
Place of Origin:
China (Mainland)
Model Number:
A20-T15-B2-A
Brand Name:
Tonhe
Rated Voltage:
DC5V/12V/24V,DC9-35V,AC/DC9-24V
Life Time:
70000 Times
Protection Class:
IP67
Certification:
CE, NSF61
SupplyAbility
SupplyAbility:
6000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Carton
Port
Ningbo



TONHEV is a manufacture in China specilized in mini motorized shut off ball valve (1/2”~2’’).And valve actuator which are approved CE certification and SS valve approved NSF61 international certification.Our company also approved SGS ISO9001 in 2013 .





Size NPT/BSP 1/4" NPT/BSP 1/2"' NPT/BSP 3/4'' NPT/BSP 1" NPT/BSP 1 1/4'' (Optional )

Material Brass
Fields of applications Water
Maximum working pressure 1.0MPa
Rated VoltageDC3V/DC5V/DC12V/DC24V (pls confirm the voltage)
Packaging Standard export package or Customized
PaymentL/C,D/P,T/T
Sample DeliveryNingbo Port,1-3 days after payment



Design Features



1 All-copper gear design, high accuracy output torque, especially for multi-channel scaling system.

2 Small size, compact structure.
3 A variety of control methods, either to accept remote valve position control signal, but also the feedback signal in place for computer intelligence unit testing.
4 Good sealing performance



15 .jpg



 4zhang2



For occasions

1 IC card water meter, heat meter.

2 Air-conditioning fan coil, fire sprinkler.
3 Solar energy drain valve, high efficiency water-saving.
4 Automatic control systems, university water system, small-scale industrial automation  equipment,  environmental protection.





Detailed information



A20 .jpg



Technical Parameters:



Valve size -------------------  1/2” - 1” (Optional)

Valve Body material -------  Brass

Actuator material ----------  Engineering Plastics

Sealing material ------------  EPDM & PTFE

Rated voltage --------------  DC5V, DC12V, DC24, DC/AC9-35V(Optional)

Wiring control methods ------- CR2-01,R3-01, CR3-02, CR3-03, CR3-04,CR5-01, CR7-01,

                                                     CR7-02, CR7-03,CR4-01(Optional)

Working current -----------  ≤500MA

Life time  -------------------  70,000 times

Protection class  -----------  IP67

Open/close time    --------- ≤5 S

Actuator rotation  ---------- 90°

Max. torque force  --------- 2Nm

Cable Length --------------  0.5m, 1.5m (Optional)

Manual override   ---------- NO

Indicator   ------------------ No

Maximum working pressure --------- 1.0MPa

Circulation medium -------------------  Fluid, Air

Environment temperature ----------  15℃~50℃

Liquid temperature ------------------   2℃~90℃



4



HTB1y.3JGVXXXXa.aXXXq6xXFXXXt
